KASIN
Low Initial Cost
• Advanced manufacturing methods and innovative material allow us to offer higher capacity ratings at a more competitive price than ever before possible.
Easy to Install
• The compound root radius in the element teeth (patent #6,342,011) increases flexibility for easier and quicker assembly. • The coupling can be blind assembled from either direction.
Protects Equipment
• Compound root radius on inner corners of flex element (patent #6,342,011) acts as a stress relief for longer element life.
• Special hub feature reduces reaction loads transferred to connected equipment (patent #6,648,763).
Tough, Long-Lasting
• Polyurethane element has excellent wear and chemical resistance, and an operating temperature of -40°C (-40°F) to 95°C (200°F).
• Weather-resistant, high-grade nylon cover is standard.
• Optional carbon steel covers with black epoxy coating are suitable for highlycorrosive, severe-duty applications. (Standard for sizes 60-80.)
• Optional stainless steel hubs are available for Type R10 when required in the food industry or corrosive environments.
Safety First
• Two stainless steel button head cap screws, positioned 180° apart, prevent relative motion between cover and element and provide a positive means of retaining the cover to the element.
• Flexible element is retained after failure, helping minimize the potential for damage or personal injury.
Quick and Easy Retrofits
• Compact design eliminates the need for coupling guard redesign on existing applications.
• Stock finished bores in popular sizes. Taper bores for QD and Taper-Lock bushings are available off-the-shelf from our worldwide distribution network.
Low Initial Cost
• Advanced manufacturing methods and innovative material allow us to offer higher capacity ratings at a more competitive price than ever before possible.
Easy to Install
• The compound root radius in the element teeth (patent #6,342,011) increases flexibility for easier and quicker assembly. • The coupling can be blind assembled from either direction.
Protects Equipment
• Compound root radius on inner corners of flex element (patent #6,342,011) acts as a stress relief for longer element life.
• Special hub feature reduces reaction loads transferred to connected equipment (patent #6,648,763).
Tough, Long-Lasting
• Polyurethane element has excellent wear and chemical resistance, and an operating temperature of -40°C (-40°F) to 95°C (200°F).
• Weather-resistant, high-grade nylon cover is standard.
• Optional carbon steel covers with black epoxy coating are suitable for highlycorrosive, severe-duty applications. (Standard for sizes 60-80.)
• Optional stainless steel hubs are available for Type R10 when required in the food industry or corrosive environments.
Safety First
• Two stainless steel button head cap screws, positioned 180° apart, prevent relative motion between cover and element and provide a positive means of retaining the cover to the element.
• Flexible element is retained after failure, helping minimize the potential for damage or personal injury.
Quick and Easy Retrofits
• Compact design eliminates the need for coupling guard redesign on existing applications.
• Stock finished bores in popular sizes. Taper bores for QD and Taper-Lock bushings are available off-the-shelf from our worldwide distribution network.
